Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can be
adjusted using setting data.
Parameter Description Value Can be set in SD
PL Machining plane Defined in MD
52005
G Change in thread pitch per revolution – (only for P = mm/rev or
in/rev):
Without change in thread pitch
0
D0 Initial plunge depth for reworking the threads 0 mm
½ Halve first infeed depth Yes
VR Return distance 2 mm x
Multiple threads 1 thread No
α0 Starting angle offset 0°
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Parameter "Face thread" in the "Input complete" mode
G code program parameters ShopTurn program parameters
Input
● Complete
PL Machining plane T Tool name
D Cutting edge number
S / V Spindle speed or constant cutting
rate
rpm
m/min
Programming technology functions (cycles)
10.2 Rotate
Turning
Operating Manual, 06/2019, A5E44903486B AB 429
