Parameter Description Unit
P1 Thread pitch 2 (unit as parameterized for P0) mm/rev
in/rev
turns/"
MODULUS
X2 or
X2α
● Intermediate point 2 X ∅ (abs) or
● Intermediate point 2 in relation to X1 (inc) or
Thread taper 2
Incremental dimensions: The sign is also evaluated
mm
Degrees
Z2
● Intermediate point 2 Z (abs) or
● Intermediate point 2 in relation to Z1 (inc)
mm
P2 Thread pitch 3 (unit as parameterized for P0) mm/rev
in/rev
turns/"
MODULUS
X3
● End point X ∅ (abs) or
● End point 3 in relation to X2 (inc) or
● Thread taper 3
mm
Degrees
Z3
● End point Z ∅ (abs) or
● End point with reference to Z2 (inc)
mm
LW Thread advance (inc) mm
LR Thread run-out (inc) mm
H1 Thread depth (inc) mm
DP or αP Infeed slope (flank) or infeed slope (angle) mm or
degrees
Infeed along the flank
Infeed with alternating flanks
D1 or ND First infeed depth or number of roughing cuts (only for ∇ and ∇ + ∇∇∇) mm
U Finishing allowance in X and Z – (only for ∇ and ∇ + ∇∇∇) mm
NN Number of noncuts - (only for ∇∇∇ and ∇ + ∇∇∇)
Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can be
adjusted using setting data.
Parameter Description Value Can be set in SD
PL Machining plane Defined in MD
52005
VR Return distance 2 mm x
Multiple threads 1 Thread No
α0 Starting angle offset 0°
Programming technology functions (cycles)
10.2 Rotate
Turning
Operating Manual, 06/2019, A5E44903486B AB 439
