Procedure
1. The part program or ShopTurn program to be processed has been cre‐
ated and you are in the editor.
2. Press the "Turning" softkey.
3. Press the "Cut-off” softkey.
The "Cut-off" input window opens.
Parameters, G code program Parameters, ShopTurn program
PL Machining plane T Tool name
SC Safety clearance mm D Cutting edge number
F Feedrate * F Feedrate mm/rev
S / V Spindle speed or constant cutting
rate
rpm
m/min
Parameter Description Unit
DIR
(only for G code)
Direction of spindle rotation
S Spindle speed rev/min
V Constant cutting rate m/min
SV Maximum speed limit - (only for constant cutting rate V) rev/min
X0 Reference point in X ∅ (abs, always diameter) mm
Z0 Reference point in Z (abs) mm
FS or R Chamfer width or rounding radius mm
X1 Depth for speed reduction ∅ (abs) or depth for speed reduction in relation to X0 (inc) mm
FR
(only for ShopTurn)
Reduced feedrate mm/rev
FR
(only for G code)
*
SR Reduced speed rev/min
X2 Final depth ∅ (abs) or final depth in relation to X1 (inc) mm
* Unit of feedrate as programmed before the cycle call
Programming technology functions (cycles)
10.2 Rotate
Turning
Operating Manual, 06/2019, A5E44903486B AB 441
