Procedure
1. The part program or ShopTurn program to be processed has been cre‐
ated and you are in the editor.
2. Press the "Contour turning" softkey.
3. Press the "Contour" and "New contour" softkeys.
The "New Contour" input window opens.
4. Enter a name for the new contour. The contour name must be unique.
5. Press the "Accept" softkey.
The input window for the starting point of the contour appears.
Enter the individual contour elements (see Section "Creating contour
elements").
Parameter Description Unit
Z Starting point Z (abs) mm
X Starting point X ∅ (abs) mm
Transition to con‐
tour start
Type of transition
● Radius
● Chamfer
FS=0 or R=0: No transition element
R Transition to following element – radius mm
FS Transition to following element – chamfer mm
Programming technology functions (cycles)
10.3 Contour turning
Turning
Operating Manual, 06/2019, A5E44903486B AB 445
