Parameter Description Unit
Allowance Allowance for pre-finishing - (only for ∇∇∇)
● Yes
U1 contour allowance
● No
U1 Compensation allowance in X and Z direction (inc) – (only for allowance)
● Positive value: Compensation allowance is retained
● Negative value: Compensation allowance is removed in addition to finishing
allowance
mm
Set machining area
limits
Set machining area limits
● Yes
● No
XA
XB
ZA
ZB
With limited machining area only, yes:
1. Limit XA ∅
2. Limit XB ∅ (abs) or 2nd limit referred to XA (inc)
1. Limit ZA
2. Limit ZB (abs) or 2nd limit referred to ZA (inc)
mm
Relief cuts Machine relief cuts
● Yes
● No
FR Insertion feedrate, relief cuts
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters ShopTurn program parameters
Input
● simple
PRG Name of the program to be generated T Tool name
D Cutting edge number
RP Retraction plane – (only for
machining direction, longitu‐
dinal, inner)
mm F Feedrate mm/rev
F Feedrate * S / V Spindle speed or constant cutting
rate
m/min
Programming technology functions (cycles)
10.3 Contour turning
Turning
462 Operating Manual, 06/2019, A5E44903486B AB
