Parameter Description Unit
XA
XB
ZA
ZB
with limited machining area only, yes:
1st limit XA ∅
2nd limit XB ∅ (abs) or 2nd limit referred to XA (inc)
1st limit ZA
2nd limit ZB (abs) or 2nd limit referred to ZA (inc)
mm
N Number of grooves
DP Distance between grooves mm
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters ShopTurn program parameters
Input
● simple
PRG Name of the program to be generated T Tool name
PL Machining plane D Cutting edge number
RP Retraction plane – (only for
machining direction, longitu‐
dinal, inner)
mm S / V Spindle speed or constant cutting
rate
m/min
Parameter Description Unit
FX (only ShopTurn)
● Feedrate in X direction
mm/rev
FZ (only ShopTurn)
● Feedrate in Z direction
mm/rev
FX (only G Code)
● Feedrate in X direction
*
FZ (only for G code)
● Feedrate in Z direction
*
Machining
● ∇ (roughing)
● ∇∇∇ (finishing)
● ∇+∇∇∇ (complete machining)
Machining
direction
● face
● longitudinal
Position
● front
● back
● inside
● outside
D Maximum depth infeed - (only for ∇) mm
XDA 1. Grooving limit tool (abs) – (only for face machining direction) mm
XDB 2. Grooving limit tool (abs) – (only for face machining direction) mm
UX or U Finishing allowance in X or finishing allowance in X and Z – (only for ∇) mm
UZ Finishing allowance in Z – (only for UX) mm
Programming technology functions (cycles)
10.3 Contour turning
Turning
480 Operating Manual, 06/2019, A5E44903486B AB
