Parameter Description
(only for ShopTurn)
Clamp/release spindle (only for face C/face C, if inserted vertically)
The function must be set up by the machine manufacturer
FZ
(only for G code)
Depth infeed rate – (for vertical insertion only) *
FZ
(only for ShopTurn)
Depth infeed rate – (for vertical insertion only) mm/min
mm/tooth
EP Maximum pitch of helix – (for helical insertion only) mm/rev
ER Radius of helix – (for helical insertion only)
The radius cannot be any larger than the milling cutter radius; otherwise, material will
remain.
mm
EW Maximum insertion angle – (for insertion with oscillation only) Degrees
FS Chamfer width for chamfering - (for chamfering only) mm
ZFS Insertion depth of tool tip (abs or inc) – (for chamfering only) mm
* Unit of feedrate as programmed before the cycle call
Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can be
adjusted using setting data.
Parameter Description Value Can be set in SD
PL (only for G code) Machining plane Defined in MD
52005
SC (only for G
code)
Safety clearance 1 mm x
Reference point Position of the reference point: Center
Machining
position
Mill rectangular pocket at the programmed position (X0, Y0,
Z0).
Single posi‐
tion
α0 Angle of rotation 0°
Solid machining The rectangular pocket is milled from the solid material - (only
for roughing)
Complete
machining
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Programming technology functions (cycles)
10.4 Milling
Turning
Operating Manual, 06/2019, A5E44903486B AB 497
