Parameter Description Unit
Machining posi‐
tion
● Single position
Mill rectangular pocket at the programmed position (X0, Y0, Z0).
● Position pattern
Position with MCALL
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X – (only for single position)
Reference point Y – (only for single position)
Reference point Z
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for Shop‐
Turn)
Face C: The positions refer to the reference point:
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
mm
mm
mm
CP
X0 or L0
Y0 or C0
Z0
(only for Shop‐
Turn)
Face Y: The positions refer to the reference point:
Positioning angle for machining area – (only single position)
Angle CP does not have any effect on the machining position in relation to the workpiece.
It is only used to position the workpiece with the rotary axis C in such a way that machining
is possible on the machine.
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
Degrees
mm
mm or de‐
grees
mm
Y0 or C0
Z0
X0
(only for Shop‐
Turn)
Peripheral surface C: The positions refer to the reference point:
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
Cylinder diameter ∅ – (only for single position)
mm or de‐
grees
mm
mm
C0
Y0
Z0
X0
(only for Shop‐
Turn)
Peripheral surface Y: The positions refer to the reference point:
Positioning angle for machining surface – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
Reference point X – (only for single position)
Degrees
mm
mm
mm
W Width of spigot mm
L Length of spigot mm
R Corner radius mm
α0 Angle of rotation Degrees
Z1 Spigot depth (abs) or depth relative to Z0 or X0 (inc) - (only for ∇ and ∇∇∇) mm
Programming technology functions (cycles)
10.4 Milling
Turning
510 Operating Manual, 06/2019, A5E44903486B AB
