Parameter Description Unit
Machining
position
● Single position
A slot is milled at the programmed position (X0, Y0, Z0).
● Position pattern
Several slots are milled at the programmed position pattern (e.g. pitch circle, grid,
line).
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X – (only for single position)
Reference point Y – (only for single position)
Reference point Z
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for Shop‐
Turn)
Face C: The positions refer to the reference point:
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
mm
mm or de‐
grees
mm
CP
X0 or L0
Y0 or C0
Z0
(only for Shop‐
Turn)
Face Y: The positions refer to the reference point:
Positioning angle for machining area – (only single position)
Angle CP does not have any effect on the machining position in relation to the workpiece.
It is only used to position the workpiece with the rotary axis C in such a way that machining
is possible on the machine.
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Degrees
mm
mm or de‐
grees
mm
Y0 or C0
Z0
X0
(only for Shop‐
Turn)
Peripheral surface C: The positions refer to the reference point:
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Cylinder diameter ∅ – (only for single position)
mm or de‐
grees
mm
mm
C0
Y0
Z0
X0
(only for Shop‐
Turn)
Peripheral surface Y: The positions refer to the reference point:
Positioning angle for machining surface – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
Reference point X – (only for single position)
Degrees
mm
mm
mm
W Slot width mm
L Slot length mm
α0 Angle of rotation of slot
Face: α0 refers to the X axis or to the position of C0 for a polar reference point
Peripheral surface: α0 refers to the Y axis
Degrees
Programming technology functions (cycles)
10.4 Milling
Turning
528 Operating Manual, 06/2019, A5E44903486B AB
