Parameter Description Unit
ER
(only for G code)
Radius of helix – (for helical insertion only)
The radius cannot be any larger than the milling cutter radius; otherwise, material will
remain.
mm
EW Maximum insertion angle – (for insertion with oscillation only) Degrees
FS Chamfer width for chamfering - (for chamfering only) mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
Note
Predrilling position
The position at which inserting takes place if "predrilled" is selected is the same position that
you select if the reference point "inside left" is specified. In the case of a groove without an angle
of rotation, the predrilling position is the center point of the left rounding radius of the groove.
When calling the cycle on a position circle, the predrilling position is always the center point of
the rounding radius that is closer to the center of the circle.
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters ShopTurn program parameters
Input
● simple
Milling direction T Tool name
RP Retraction plane mm D Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description
Machining
surface
● Face C
● Face Y
● Peripheral surface C
● Peripheral surface Y
Position
(only for ShopTurn)
● At the front (face)
● At the rear (face)
● Outside (peripheral surface)
● Inside (peripheral surface)
Programming technology functions (cycles)
10.4 Milling
Turning
530 Operating Manual, 06/2019, A5E44903486B AB
