Additional supplementary conditions
● Finishing
1/2 slot width W ≤ milling cutter diameter
● Edge finishing
Finishing allowance UXY ≤ milling cutter diameter
● Chamfering
The tip angle must be entered into the tool table.
Procedure
1. The part program or ShopTurn program to be processed has been cre‐
ated and you are in the editor.
2. Press the "Milling" softkey.
3. Press the "Slot" and "Open slot" softkeys.
The "Open slot" input window opens.
Parameters in the "Input complete" mode
G code program parameters ShopTurn program parameters
Input
● Complete
PL Machining plane T Tool name
RP Retraction plane mm D Cutting edge number
SC Safety clearance mm F Feedrate mm/min
mm/tooth
F Feedrate * S / V Spindle speed or constant cutting
rate
rpm
m/min
Programming technology functions (cycles)
10.4 Milling
Turning
546 Operating Manual, 06/2019, A5E44903486B AB
