Mirror writing
You can engrave the text mirrored on the workpiece.
Full circle
If you want to distribute the characters evenly around a full circle, enter the arc angle α2=360°.
The cycle then distributes the characters evenly around the full circle.
Parameters, G code program Parameters, ShopTurn program
PL Machining plane T Tool name
Milling direction D Cutting edge number
RP Retraction plane mm F Feedrate mm/min
mm/tooth
SC Safety clearance mm S / V Spindle speed or constant cutting
rate
rpm
m/min
F Feedrate mm/min
Parameter Description Unit
FZ
(only for G code)
Depth infeed rate *
FZ
(only for Shop‐
Turn)
Depth infeed rate mm/min
mm/tooth
Machining
surface
(only for Shop‐
Turn)
● Face C
● Face Y
● Peripheral surface C
● Peripheral surface Y
Position
(only for Shop‐
Turn)
● At the front (face)
● At the rear (face)
● Outside (peripheral surface)
● Inside (peripheral surface)
(only for Shop‐
Turn)
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
Alignment
● (linear alignment)
● (curved alignment)
● (curved alignment)
Programming technology functions (cycles)
10.4 Milling
Turning
Operating Manual, 06/2019, A5E44903486B AB 561
