Parameter Description Unit
EP Maximum pitch of helix – (for helical insertion only) mm/rev
ER Radius of helix – (for helical insertion only)
The radius cannot be any larger than the milling cutter radius; otherwise, material will
remain.
mm
EW Note:
During insertion with oscillation, the message “Ramp path too short” will appear if the tool
is less than the milling cutter diameter away from the insertion point along the ramp. If this
occurs, please reduce the angle of insertion.
Degrees
Lift mode Lift mode before new infeed
If the machining operation requires several points of insertion, the retraction height can be
programmed:
● To retraction plane
● Z0 + safety clearance
When making the transition to the next insertion point, the tool returns to this height. If
there are no elements larger than Z0 (X0) in the pocket area, then Z0 (X0) + safety
clearance can be programmed as the lift mode.
mm
mm
FS Chamfer width for chamfering - (only for chamfering machining) mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering machining only) mm
Parameters in the "Input simple" mode
G code program parameters ShopTurn program parameters
Input
● simple
PRG
● Name of the program to be generated
● Automatic
Automatic generation of program names
T Tool name
Milling direction
● Climbing
● Conventional
D Cutting edge number
RP Retraction plane mm F Feedrate mm/min
mm/rev
F Feedrate * S / V Spindle speed or constant
cutting rate
rpm
m/min
Programming technology functions (cycles)
10.5 Contour milling
Turning
Operating Manual, 06/2019, A5E44903486B AB 591
