Procedure
1. The part program to be edited has been created and you are in the editor.
2. Press the "Various" softkey.
3. Press the ">>" and "Adjust to load" softkeys.
The input window "Adjust to load" opens.
Parameter Description Unit
Axis Channel axis name
Axis dynamics
● Default
Adaptation deactivated. The default controller settings are used.
● Adapt
Adaptation activated. The controller settings are adapted to the currently active
load.
Entire load Currently active load
● Measure:
Travel movements are executed to derive the load.
● Set:
Fixed value for the moment of inertia is applied.
Measurement result
display
Measurement result display
● On
● Off
Display mode Duration of measurement result display
● autom. 8s
Disappears automatically after 8 s
● NC Start
Acknowledge the display with the <NC-START> key
Moment of inertia Moment of inertia of the entire load
The value of the most recent measurement can be applied with the softkey "Insert
last result".
kgm
2
Mass Mass of the entire load (only for linear axes with linear drives) kg
Programming technology functions (cycles)
10.6 Further cycles and functions
Turning
