Parameter Meaning
Length X Length Z
Geometry Geometry data, length
X
Geometry data, length Z
Wear Length X wear Length Y wear
Radius
Geometry Tool radius
Wear Radius wear
For type 500 (rougher) and type 510 (finisher)
Cutting edge graphic
The cutting edge graphic shows the positioning defined by the
holder angle, cut direction and cutting tip angle.
Reference direction
The reference direction for the holder angle specifies the cut
direction.
Holder angle To determine the cutting edge positioning
Cutting tip angle To determine the cutting edge positioning
Type 240 - tap
Pitch
Type 200 - twist drill, type 220 - centering tool and type 230 - countersink
Tip angle
Type 520 -plunge cutter, type 530 - parting tool, type 540 - threading tool
Cutting tip length For displaying the tools during the simulation of the program execution
Cutting tip width Width of the plunge cutter
Type 110 - ball end mill for cylindrical die-sinking cutter, type 111 - ball end mill for tapered die-sinking cutter, type 120 - end
mill, type 121 - end mill with corner rounding, type 130 - angle head cutter, type 140 - facing tool, type 150 - side mill, type 155
- bevel cutter, type 156 - bevel cutter with corner rounding and type 157 - tapered die-sinking cutter
N Number of teeth
For driven tools (drills and milling tools)
Direction of
spindle rotation
Spindle is not switched on
CW spindle rotation
CCW spindle rotation
Coolant 1 and 2 (e.g. internal and external cooling) can be switched on and off.
Please refer to the machine manufacturer's specifications.
Cutting edge OEM
parameters 1 - 2
Tool management
13.9 Tool details
Turning
Operating Manual, 06/2019, A5E44903486B AB 755
