3. Enter the user name and password and press the "OK" softkey to log into

the FTP server.

The content of the FTP server with its folders is displayed.

4. Press the "Log out" softkey after the required data processing has been

completed.

The connection to the FTP server is disconnected. In order to reselect

the FTP drive, you must log on again.

Managing programs

14.1 Overview

Turning

Operating Manual, 06/2019, A5E44903486B AB 781
