Closing the program

Press the ">>" and "Exit" softkeys to close the program and editor again.

- OR -

If you are at the start of the first line of the program, press the <Cursor left> key

to close the program and the editor.

To reopen a program you have exited with "Close", press the "Program" key.

Note

A program does not have to be closed in order for it to be executed.

Managing programs

14.2 Opening and closing the program

Turning
