3. Press the "Glob. settings" softkey.

4. Enter the user name and the associated password for the configured

drives to be released.

5. Press the "OK" softkey.

The specifications are transferred as default setting for the Windows re‐

lease.

If you press the "Cancel" softkey, then all of the data that has not been

activated is rejected.

Managing programs

14.12 Set up drives

Turning

810 Operating Manual, 06/2019, A5E44903486B AB

Default Chapter5
- Preface5
- Table of Contents9
