Data
Zero points
● No
The selection box "Basis zero point" is hidden
● All used in the program (only for ShopTurn program and job list only
with ShopTurn programs)
● All
Zero points for ShopTurn
programs
-- only available for job list
with ShopTurn and G
code programs
● No
The selection box "Basis zero point" is hidden
● All used in the program
● Complete tool list
Zero points for G code pro‐
grams
-- only available for job list
with ShopTurn and G
code programs
● No
The selection box "Basis zero point" is hidden
● All
Basic zero points
● No
● Yes
Directory The directory is displayed, in which the selected program is located.
File name Here you have the option of changing the suggested file names.
Note
Magazine assignment
You can only read out the magazine assignments if your system provides support for loading
and unloading tool data to and from the magazine.
Procedure
1. Select the "Program Manager" operating area.
...
2. Position the cursor on the program whose tool and zero point data
you wish to back up.
3. Press the ">>" and "Archive" softkeys.
4. Press the "Setup data" softkey.
The "Backup setup data" window opens.
Managing programs
14.17 Setup data
Turning
824 Operating Manual, 06/2019, A5E44903486B AB
