Symbol Meaning

RESET alarm

Cancel alarm

HMI alarm

Dialog alarms of the HMI

PLC alarm

PLC alarm of the SQ type (alarm number from 800000)

Safety alarms

Machine manufacturer

Please refer to the machine manufacturer's instructions.

Alarm, error and system messages

15.1 Displaying alarms

Turning

Operating Manual, 06/2019, A5E44903486B AB 837
