Procedure

1. Teach-in mode is active.

2. Select the program block to be deleted.

3. Press the ">>" and "Delete block" softkeys.

The program block on which the cursor is positioned is deleted.

Teaching in a program

19.3 Processing a program

Turning

898 Operating Manual, 06/2019, A5E44903486B AB
