Softkeys on the machine control panel menu

Available softkeys:

"Machine" softkey Select the "Machine" operating area

"[VAR]" softkey Select the axis feedrate in the variable increment

"1… n CHANNEL"

softkey

Changing the channel

"Single Block" soft‐

key

Switch single block execution on/off

"WCS MCS" softkey Switch between WCS and MCS

"Back" softkey Close window

Note

The window will automatically disappear when changing regions areas with the <MENU

SELECT> key.
