Procedure

1. The "Ctrl-E Analysis" window is open.

2. Press the "Long time measurement" softkey.

The "SINUMERIK Ctrl-Energy Analysis Long-term Measurement" win‐

dow opens.

The results of the long-term measurement are displayed.

3. Press the "Back" softkey to terminate the long-term measurement.

Ctrl-Energy

21.2 Ctrl-E analysis

Turning

920 Operating Manual, 06/2019, A5E44903486B AB
