Select "REPOS"
Press the <REPOS> key.
"MDI" mode (Manual Data Input)
In "MDI" mode, you can enter and execute G code commands non-modally to set up the
machine or to perform a single action.
Selecting "MDI"
Press the <MDI> key.
The "TEACH IN" function is available in "MDI" mode.
"TEACH IN" function
With the "TEACH IN" function, you can create, edit and execute part programs (main programs
and subroutines) for motion sequences or simple workpieces by approaching and saving
positions.
Selecting "Teach In"
Press the <TEACH IN> key.
"AUTO" mode
In automatic mode, you can execute a program completely or only partially.
Select "AUTO"
Press the <AUTO> key.
The "Single block" function is available in "AUTO" mode.
"Single block" function
You can execute a program block-by-block with the "Single block" function.
Select "Single block"
Press the <SINGLE BLOCK> key.
Setting up the machine
4.3 Modes and mode groups
Turning
98 Operating Manual, 06/2019, A5E44903486B AB
