Procedure
1Removethetopcoverofthewoodentransport
box.
2PulloutallthenailsmarkedwithIndianink.
3Removethesupporthardware(woodencradle
andsupportconstruction).
Ifyouwishtoreusethetransportbox,make
surethatyoukeepallthesupporthardware
usedtosecurethehullunit.
4Fastentheliftingtackletothetwoliftingeye
boltsoneithersideofthetopofthegantry.
5Liftthehullunit(withthetransducerprotectionstillinplace!)carefullyoutof
thetransportbox.
Note
Verifythatyouusethecorrectliftingeye!Therearetwoliftingeyesoneachside
ofthehullunit.Oneislocatedonthetopofthegantry,andoneonthetopofthe
transducershaft.Makesurethatyouusetheliftingeyeonthegantrywhenyoulift
thehullunitoutofthetransportbox!
6Whilelifting,makesurethatyoudonotdamagethedelicatepartsofthehullunit.
Note
Makesurethatyoukeepthetransducersafe,andthetransducercableand
connectordry.Watchthesecarefullytopreventthesedelicatepartsfrombeing
damaged,stuckorhookedontoprotrudingobjectswhilemanoeuvringthehullunit
intothesonarroom.Donotremovethetransducerprotection(thethickfoam)until
justbeforethehullunitisloweredontotheinstallationtrunk.
Relatedtopics
Installingthehullunit,page124
Hullunitinstallationoverview,page125
Installingthehullunit
