Simrad ST90 Installation Manual

178
442703/B
EEthernetcable:ThesearesocketsforbreopticEthernetcables.Theyarecurrently
notinuse.
FEthernetcable:FromProcessorUnittoTransceiverUnit(C8)
ThemaximumlengthofeachEthernetcablefromtheProcessorUnittothe
TransceiverUnitis100meters.
Itisveryimportantthathigh-qualityEthernetcablesareused.Youmustuse
CAT-5ESTP(ShieldedTwistedPair)qualityorbetter.Ifyouusecableswithlower
bandwidthcapacityyouwillreducetheST90performance.Donot
connectthe
ProcessorUnittotheTransceiverUnitusinganexistinglocalareanetwork(LAN).
GSerialcable:FromProcessorUnittoexternaldevice(s)(C13)
Note
IfyouuseOperatingPanelMk1onyourST90,thissocketisusedforthecontrol
cablebetweentheProcessorUnitandtheoperatingpanel.
HACpowercable:FromProcessorUnittouninterruptiblepowersupply(UPS)(C3)
IPowerOn/Off
JGroundcable:FromProcessorUnittovesselground(C6)
KControlcable:FromProcessorUnittoOperatingPanelThiscableisonlyusedwith
OperatingPanelMk1.
ThisisastandardcommercialUSBdatacable.IthasaquadraticUSBconnectorin
theOperatingPanelend(B-plug),andrectangularUSBconnectorintheProcessor
Unitend(A-plug).
LVideocable
MEthernetcable(ETH1):FromProcessorUnittoOperatingPanel(C12)
TheconnectionmaybemadethroughanEthernetswitch.Donot
usetheadapter
inSlotF.
NEthernetcable(ETH2):FromProcessorUnittolocalareanetwork(LAN)(C14)
Donot
usetheadapterinSlotF.
ONotused
PNotused
Relatedtopics
InstallingtheST90cables,page171
InstallingtheST90topsidecables,page172
