Illustration:
Roxtecsteps(ImagefromRoxtecwebsite)
TheRoxtecsystemisavailablewithalarge
numberofvariousmodulesandcompression
units.Thesystemcomplieswithcurrent
screeningandEMCrequirements.
Procedure
1Cutanopeninginthestructure(bulkhead,
cabinetetc)youwishtopenetrate.
Theholemustbelargeenoughtotone
ofthestandardrectangularorcircular
framesprovidedbythesealingsystem
manufacturer.
Note
Thechosensolutionmustcomplywiththe
reand/orpressuredemandsforthevessel.
Ifthesealingistobeusedunderwater ,both
pressureandmaterialrequirementsmust
betakenintoconsideration.
2Mounttheframe.
3Pullthecable(s)throughtheframe.
Inmostcasestheopeningwillbelarge
enoughtoaccepttheplugsonthecables.
4Secureeachcablewithasquaresealing
module.
5Adjustthemoduletotthecable’souter
diameter.
6Whentherequirednumberofmodulesareinstalled,tightentheassemblywitha
compressionunit.
Furtherrequirements
Foracompleteinstallationprocedure,refertotherelevantdocumentationprovidedby
themanufacturer.
