UM0306 Real-Time Clock (RTC)

129/519

8.4.4 RTC prescaler divider register (RTC_DIVH / RTC_DIVL)

During each period of TR_CLK, the counter inside the RTC prescaler is reloaded with the

value stored in the RTC_PRL register. To get an accurate time measurement it is possible to

read the current value of the prescaler counter, stored in the RTC_DIV register, without

stopping it. This register is read-only and it is reloaded by hardware after any change in the

RTC_PRL or RTC_CNT registers.

RTC prescaler divider register high (RTC_DIVH)

Address Offset: 10h

Reset value: 0000h

RTC prescaler divider register low (RTC_DIVL)

Address Offset: 14h

Reset value: 8000h

1514131211109876 5 43210

Reserved RTC_DIV[19:16]

rrrr

Bits 15:4 Reserved

Bits 3:0 RTC_DIV[19:16]: RTC Clock Divider High

1514131211109876 5 43210

RTC_DIV[15:0]

rrrrrrrrrr r rrrrr

Bits 15:0 RTC_DIV[15:0]: RTC Clock Divider Low
