Page #191 background image
UM0306 Advanced control timer (TIM1)
191/519
12.5 TIM1 register description
Refer to Section 1.1 on page 23 for a list of abbreviations used in register descriptions.
12.5.1 Control register 1 (TIM1_CR1)
Address offset: 00h
Reset value: 0000h
1514131211109876543210
Reserved CKD[1:0] ARPE CMS[1:0] DIR OPM URS UDIS CEN
rw rw rw rw rw rw rw rw rw rw
Bits 15:10 Reserved, always read as 0
Bits 9:8
CKD[1:0]: Clock division.
This bit-field indicates the division ratio between the timer clock (CK_INT) frequency
and the dead-time and sampling clock used by the dead-time generators and the
digital filters (ETR, TIx),
00: t
DTS
=t
CK_INT
01: t
DTS
=2*t
CK_INT
10: t
DTS
=4*t
CK_INT
11: Reserved, do not program this value.
Bit 7
ARPE: Auto-reload preload enable.
0: TIM1_ARR register is not buffered.
1: TIM1_ARR register is buffered.
Bits 6:5
CMS[1:0]: Center-aligned mode selection.
00: Edge-aligned mode. The counter counts up or down depending on the direction
bit (DIR).
01: Center-aligned mode 1. The counter counts up and down alternatively. Output
compare interrupt flags of channels configured in output (CCxS=00 in TIM1_CCMRx
register) are set only when the counter is counting down.
10: Center-aligned mode 2. The counter counts up and down alternatively. Output
compare interrupt flags of channels configured in output (CCxS=00 in TIM1_CCMRx
register) are set only when the counter is counting up.
11: Center-aligned mode 3. The counter counts up and down alternatively. Output
compare interrupt flags of channels configured in output (CCxS=00 in TIM1_CCMRx
register) are set both when the counter is counting up or down.
Note: It is not allowed to switch from edge-aligned mode to center-aligned mode as
long as the counter is enabled (CEN=1)
Bit 4
DIR: Direction.
0: Counter used as up-counter.
1: Counter used as down-counter.
Note: This bit is read only when the timer is configured in Center-aligned mode or
Encoder mode.
Bit 3
OPM: One pulse mode.
0: Counter is not stopped at update event
1: Counter stops counting at the next update event (clearing the bit CEN).
