UM0306 Window watchdog (WWDG)

149/519

11.6.3 Status register (WWDG_SR)

Address Offset: 08h

Reset Value: 0000 0000 (00h)

Bits 8:7

WDGTB[1:0]: Timer Base

The time base of the prescaler can be modified as follows:

00: CK Counter Clock (PCLK1 div 4096) div 1

01: CK Counter Clock (PCLK1 div 4096) div 2

10: CK Counter Clock (PCLK1 div 4096) div 4

11: CK Counter Clock (PCLK1 div 4096) div 8

Bits 6:0

W[6:0] 7-bit window value

These bits contain the window value to be compared to the downcounter.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Reserved

1514131211109876543210

Reserved EWIF

rc_w0

Bit 31:1 Reserved

Bit 0

EWIF: Early Wakeup Interrupt Flag

This bit is set by hardware when the counter has reached the value 40h. It

must be cleared by software by writing ‘0’. A write of ‘1’ has no effect. This bit

is also set if the interrupt is not enabled.
