ST STM32F10 Series - Figure 44. Update Rate Examples Depending on Mode and TIM1

To Next Page

To Previous Page

UM0306 Advanced control timer (TIM1)

163/519

Figure 44. Update rate examples depending on mode and TIM1_RCR register

settings

Center-aligned mode

Edge-aligned mode

UEV

Update Event

: Preload registers transferred to active registers and update interrupt generated

Counter

TIM1_RCR = 0

TIM1_RCR = 1

TIM1_RCR = 2

TIM1_RCR = 3

Update Event

if the repetition down-counter underflow occurs when the counter is equal to

to the auto-reload value.

UEV

TIM1_RCR

= 3

and

re-synchronization

(by SW)

TIM1_CNT

(by SW)

Up-Counting Down-Counting
