The memory buffer which is currently being used by the USB Peripheral is defined by DTOG

buffer flag, while the buffer currently in use by application software is identified by SW_BUF

buffer flag. The relationship between the buffer flag value and the used packet buffer is the

same in both cases, and it is listed in the following table.

Note: * Endpoint in NAK Status.

Double-buffering feature for a bulk endpoint is activated by:

● Writing EP_TYPE bit field at ‘00’ in its register, to define the endpoint as a bulk, and

● Setting EP_KIND bit at ‘1’ (DBL_BUF), in the same register.

The application software is responsible for DTOG and SW_BUF bits initialization according

to the first buffer to be used; this has to be done considering the special toggle-only property

that these two bits have. The end of the first transaction occurring after having set

DBL_BUF, triggers the special flow control of double-buffered bulk endpoints, which is used

for all other transactions addressed to this endpoint until DBL_BUF remain set. At the end of

each transaction the CTR_RX or CTR_TX bit of the addressed endpoint register is set,

depending on the enabled direction. At the same time, the affected DTOG bit in the register

is hardware toggled making the USB Peripheral buffer swapping completely software

independent. Unlike common transactions, and the first one after DBL_BUF setting, STAT

bit pair is not affected by the transaction termination and its value remains ‘11’ (Valid).

However, as the token packet of a new transaction is received, the actual endpoint status will

Table 55.

Double-buffering buffer flag definition

Buffer flag ‘Transmission’ endpoint ‘Reception’ endpoint

DTOG DTOG_TX ( bit 6) DTOG_RX ( bit 14)

SW_BUF bit 14 bit 6

Table 56. Bulk double-buffering memory buffers usage

Endpoint

Type

DTOG SW_BUF

Packet buffer used by USB

Peripheral

Packet buffer used by

Application Software

ADDRn_TX_0 / COUNTn_TX_0
