UM0306 General purpose and alternate function I/O (GPIO and AFIO)
79/519
Figure 13. High impedance-analog input configuration
FROM ON-CHIP
PERIPHERAL
TO ON-CHIP
PERIPHERAL
Analog Input
I/O PIN
TTL SCHMITT
TRIGGER
VSS
VDD_IO
PROTECTION
DIODE
PROTECTION
DIODE
OFF
INPUT DRIVER
0
INPUT DATA REGISTER
OUTPUT DATA REGISTER
READ/WRITE
READ
BIT SET/RESET REGISTERS
WRITE
www.BDTIC.com/ST
