USB full speed device interface (USB) UM0306
444/519
Bit 6
DTOG_TX: Data Toggle, for transmission transfers
If the endpoint is non-isochronous, this bit contains the required value of the data
toggle bit (0=DATA0, 1=DATA1) for the next data packet to be transmitted. Hardware
toggles this bit when the ACK handshake is received from the USB host, following a
data packet transmission. If the endpoint is defined as a control one, hardware sets
this bit to 1 at the reception of a SETUP PID addressed to this endpoint.
If the endpoint is using the double buffer feature, this bit is used to support packet
buffer swapping too (Refer to Section 18.5.3: Double-buffered endpoints)
If the endpoint is Isochronous, this bit is used to support packet buffer swapping since
no data toggling is used for this sort of endpoints and only DATA0 packet are
transmitted (Refer to Section 18.5.4: Isochronous transfers). Hardware toggles this bit
just after the end of data packet transmission, since no handshake is used for
Isochronous transfers.
This bit can also be toggled by the software to initialize its value (mandatory when the
endpoint is not a control one) or to force a specific data toggle/packet buffer usage.
When the application software writes ‘0’, the value of DTOG_TX remains unchanged,
while writing ‘1’ makes the bit value toggle. This bit is read/write but it can only be
toggled by writing 1.
Bits 5:4
STAT_TX [1:0]: Status bits, for transmission transfers
These bits contain the information about the endpoint status, listed in Ta bl e 62 . These
bits can be toggled by the software to initialize their value. When the application
software writes ‘0’, the value remains unchanged, while writing ‘1’ makes the bit value
toggle. Hardware sets the STAT_TX bits to NAK, when a correct transfer has occurred
(CTR_TX=1) corresponding to a IN or SETUP (control only) transaction addressed to
this endpoint. It then waits for the software to prepare the next set of data to be
transmitted.
Double-buffered bulk endpoints implement a special transaction flow control, which
controls the status based on buffer availability condition (Refer to Section 18.5.3:
Double-buffered endpoints).
If the endpoint is defined as Isochronous, its status can only be “VALID” or
“DISABLED”. Therefore, the hardware cannot change the status of the endpoint after a
successful transaction. If the software sets the STAT_TX bits to ‘STALL’ or ‘NAK’ for an
Isochronous endpoint, the USB Peripheral behavior is not defined. These bits are
read/write but they can be only toggled by writing ‘1’.
Bits 3:0
EA[3:0]: Endpoint Address.
Software must write in this field the 4-bit address used to identify the transactions
directed to this endpoint. A value must be written before enabling the corresponding
endpoint.
Table 59. Reception status encoding
STAT_RX[1:0] Meaning
00 DISABLED: all reception requests addressed to this endpoint are ignored.
01
STALL: the endpoint is stalled and all reception requests result in a STALL
handshake.
10 NAK: the endpoint is naked and all reception requests result in a NAK handshake.
11 VALID: this endpoint is enabled for reception.
