General purpose and alternate function I/O (GPIO and AFIO) UM0306

90/519

5.3.6 I2C 1 alternate function remapping

Refer to AF remap and debug I/O configuration register (AFIO_MAPR)

5.3.7 SPI 1 alternate function remapping

Refer to AF remap and debug I/O configuration register (AFIO_MAPR)

Table 21. USART2 remapping

Alternate Functions USART2_REMAP = 0 USART2_REMAP = 1

(1)

1. Remap available only for 100 pin package.

USART2_CTS PA0 PD3

USART2_RTS PA1 PD4

USART2_TX PA2 PD5

USART2_RX PA3 PD6

USART2_CK PA4 PD7

Table 22. USART1 remapping

Alternate Function USART1_REMAP = 0 USART1_REMAP = 1

USART1_TX PA9 PB6

USART1_RX PA10 PB7

Table 23. I2C1 Remapping

Alternate Function I2C1_REMAP = 0 I2C1_REMAP = 1

(1)

1. Remap not available on 128K 36 pin.

I2C1_SCL PB6 PB8

I2C1_SDA PB7 PB9

Table 24. SPI1 Remapping

Alternate Function SPI1_REMAP = 0 SPI1_REMAP = 1

SPI1_NSS PA4 PA15

SPI1_SCK PA5 PB3

SPI1_MISO PA6 PB4

SPI1_MOSI PA7 PB5
