Advanced control timer (TIM1) UM0306
208/519
12.5.8 Capture/compare mode register 2 (TIM1_CCMR2)
Address offset: 1Ch
Reset value: 0000h
Refer to the above CCMR1 register description.
Output Compare mode
Input capture mode
1514131211109876543210
OC4
CE
OC4M[2:0]
OC4
PE
OC4
FE
CC4S[1:0]
OC3
CE.
OC3M[2:0]
OC3
PE
OC3
FE
CC3S[1:0]
IC4F[3:0] IC4PSC[1:0] IC3F[3:0] IC3PSC[1:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bit 15 OC4CE: Output Compare 4 Clear Enable
Bits 14:12 OC4M: Output Compare 4 Mode.
Bit 11 OC4PE: Output Compare 4 Preload enable.
Bit 10 OC4FE: Output Compare 4 Fast enable.
Bits 9:8
CC4S: Capture/Compare 4 Selection.
This bit-field defines the direction of the channel (input/output) as well as the used
input.
00: CC4 channel is configured as output.
01: CC4 channel is configured as input, IC4 is mapped on TI4.
10: CC4 channel is configured as input, IC4 is mapped on TI3.
11: CC4 channel is configured as input, IC4 is mapped on TRGI. This mode is
working only if an internal trigger input is selected through TS bit (TIM1_SMCR
register)
Note: CC4S bits are writable only when the channel is OFF (CC4E = ’0’ in
TIM1_CCER).
Bit 7 OC3CE: Output Compare 3 Clear Enable
Bits 6:4 OC3M: Output Compare 3 Mode.
Bit 3 OC3PE: Output Compare 3 Preload enable.
Bit 2 OC3FE: Output Compare 3 Fast enable.
Bits 1:0
CC3S: Capture/Compare 3 Selection.
This bit-field defines the direction of the channel (input/output) as well as the used
input.
00: CC3 channel is configured as output.
01: CC3 channel is configured as input, IC3 is mapped on TI3.
10: CC3 channel is configured as input, IC3 is mapped on TI4.
11: CC3 channel is configured as input, IC3 is mapped on TRGI. This mode is
working only if an internal trigger input is selected through TS bit (TIM1_SMCR
register)
Note: CC3S bits are writable only when the channel is OFF (CC3E = ’0’ in
TIM1_CCER).
Bits 15:12 IC4F: Input Capture 4 Filter.
Bits 11:10 IC4PSC: Input Capture 4 Prescaler.
