UM0306 General purpose timer (TIMx)

225/519

Figure 75. Counter timing diagram, internal clock divided by 1

Figure 76. Counter timing diagram, internal clock divided by 2

Figure 77. Counter timing diagram, internal clock divided by 4

CK_INT

CNT_EN

TIMER CLOCK = CK_CNT

COUNTER REGISTER

UPDATE INTERRUPT FLAG (UIF)

COUNTER OVERFLOW

UPDATE EVENT (UEV)

01 02 03 04 05 06 0732 33 34 35 3631
