Advanced control timer (TIM1) UM0306
192/519
Bit 2
URS: Update request source.
This bit is set and cleared by software to select the UEV event sources.
0: Any of the following events generate an update interrupt or DMA request if
enabled. These events can be:
– Counter overflow/underflow
– Setting the UG bit
– Update generation through the slave mode controller
1: Only counter overflow/underflow generates an update interrupt or DMA request if
enabled.
Bit 1
UDIS: Update disable.
This bit is set and cleared by software to enable/disable UEV event generation.
0: UEV enabled. The Update (UEV) event is generated by one of the following
events:
– Counter overflow/underflow
– Setting the UG bit
– Update generation through the slave mode controller
Buffered registers are then loaded with their preload values.
1: UEV disabled. The Update event is not generated, shadow registers keep their
value (ARR, PSC, CCRx). However the counter and the prescaler are reinitialized if
the UG bit is set or if a hardware reset is received from the slave mode controller.
Bit 0
CEN: Counter enable.
0: Counter disabled
1: Counter enabled
Note: External clock, gated mode and encoder mode can work only if the CEN bit has
been previously set by software. However trigger mode can set the CEN bit
automatically by hardware.
