UM0306 Advanced control timer (TIM1)

199/519

Bit 3

CC3IE: Capture/Compare 3 interrupt enable.

0: CC3 interrupt disabled.

1: CC3 interrupt enabled.

Bit 2

CC2IE: Capture/Compare 2 interrupt enable.

0: CC2 interrupt disabled.

1: CC2 interrupt enabled.

Bit 1

CC1IE: Capture/Compare 1 interrupt enable.

0: CC1 interrupt disabled.

1: CC1 interrupt enabled.

Bit 0

UIE: Update interrupt enable.

0: Update interrupt disabled.

1: Update interrupt enabled.
