Advanced control timer (TIM1) UM0306

220/519

Refer to Table 1 on page 27 for the register boundary addresses.

38h

TIM1_CCR2

Reserved

CCR2[15:0]

Reset Value 0000000000000000

3Ch

TIM1_CCR3

Reserved

CCR3[15:0]

Reset Value 0000000000000000

40h

TIM1_CCR4

Reserved

CCR4[15:0]

Reset Value 0000000000000000

44h

TIM1_BDTR

Reserved

MOE

AOE

BKP

BKE

OSSR

OSSI

LOCK

[1:0]

DT[7:0]

Reset Value 0000000000000000

48h

TIM1_DCR

Reserved

DBL[4:0]

Reserved

DBA[4:0]

Reset Value 00000 00000

4Ch

TIM1_DMAR

Reserved

DMAB[15:0]

Reset Value 0000000000000000
