UM0306 General purpose timer (TIMx)

281/519

Refer to Table 1 on page 27 for the register boundary addresses.

38h

TIMx_CCR2

Reserved

CCR2[15:0]

Reset Value 0000000000000000

3Ch

TIMx_CCR3

Reserved

CCR3[15:0]

Reset Value 0000000000000000

40h

TIMx_CCR4

Reserved

CCR4[15:0]

Reset Value 0000000000000000

44h

Reserved

48h

TIMx_DCR

Reserved

DBL[4:0]

Reserved

DBA[4:0]

Reset Value 00000 00000

4Ch

TIMx_DMAR

Reserved

DMAB[15:0]

Reset Value 0000000000000000

Table 41. TIMx - register map and reset values (continued)
