UM0306 Reset and clock control (RCC)

63/519

Bits 20:19 Reserved, always read as 0.

Bit 18

USART3RST USART 3 reset

Set and reset by software.

0: No effect

1: Reset USART 3

Bit 17

USART2RST USART 2 reset

Set and reset by software.

0: No effect

1: Reset USART 2

Bits 16:15 Reserved, always read as 0.

Bit 14

SPI2RST SPI 2 reset

Set and reset by software.

0: No effect

1: Reset SPI 2

Bits 13:12 Reserved, always read as 0.

Bit 11

WWDGRST Window Watchdog reset

Set and reset by software.

0: No effect

1: Reset window watchdog

Bits 10:3 Reserved, always read as 0.

Bit 2

TIM4RST Timer 4 reset

Set and reset by software.

0: No effect

1: Reset timer 4

Bit 1

TIM3RST Timer 3 reset

Set and reset by software.

0: No effect

1: Reset timer 3

Bit 0

TIM2RST Timer 2 reset

Set and reset by software.

0: No effect

1: Reset timer 2
