General purpose and alternate function I/O (GPIO and AFIO) UM0306

94/519

Bit 1

I2C1_REMAP I2C1 remapping

This bit is set and cleared by software. It controls the mapping of I2C1 SCL

and SDA alternate functions on the GPIO ports.

0: No remap (SCL/PB6, SDA/PB7)

1: Remap (SCL/PB8, SDA/PB9)

Bit 0

SPI1_REMAP SPI1 remapping

This bit is set and cleared by software. It controls the mapping of SPI1 NSS,

SCK, MISO, MOSI alternate functions on the GPIO ports.

0: No remap (NSS/PA4, SCK/PA5, MISO/PA6, MOSI/PA7)

1: Remap (NSS/PA15, SCK/PB3, MISO/PB3, MOSI/PB5)
