Stoll CMS 520 C+ - Page 69

69
Description of knitting machine 2
Display and operating elements
Input elements
Input elements In the following sections three groups of input elements are shown:
 Standard input elements; these are displayed
when an input field is
activated by briefly touching in
 Selection elements; these are displayed when
a selection field is activated
by briefly touching it
 Virtual keyboard; this can be displ
ayed for inputs
Standard input elements
Standard input elements
Standard input elements
Standard input elements
Element Function
Reduce value by one step
Increase value by one step
Undo a change, the last value saved is displayed again
Undo a change, the previous value is displayed again
Confirm input, save changes, end setting process
Delete character to left of cursor
Position the cursor at the start of the line
Position the cursor at the end of the line
