70
2 Description of knitting machine
Display and operating elements
Switches and linear regulators
Switches and linear regulators
Selection elements
Selection elements
Selection elements
Selection elements
Element
Function
Only one switch can be active at
a time
Position switch (on/off)
Check box (on/off)
Arrow switch (left/right) or (up/
down)
Slider
Reduce current value by one
step
Increase current value by one
step
Element
Function
Fold open selection field
Fold closed selection field
Move cursor: one line upwards
Move cursor: one line downwards
Move cursor: one character to left
Move cursor: one character to the right
Move cursor: to first input of selection field
Move cursor: to last input of selection field
