Maintenance6606−1/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
4/ 7
D
II
H
1
H
2
12
H
3
94661−I
L
13
II
x
2
94663a−IL
94663b−IL
94663d
WCH00115
I
I
I - I
94663−IL
94048−M3
0
WCH00113
⇒ Continue drawing the cooler up to max. ’x
2
’ = 195 mm before the guide end of
supports 94663a−IL and 94663b−IL (view II).
⇒ Mount lifting plate 94663−IL to swivel lugs 94048−M30 and connect it to spur-
geared chain block H
1
.
The strand angle of max. 135_ may not be exceeded corresponding to the admis-
sible lifting capacity WLL (W
orking Load Limit) for:
− SAC261−IL WLL = 900 kg
− SAC265−IL WLL = 1200 kg
⇒ Take over the full weight of the cooler using spur-geared chain blocks H
1
and
H
2
.
⇒ Remove lugs 94663c−IL, safety chains 94663d, manual ratchet H
3
and sup-
port 94661−IL.
⇒ Move the cooler till the trolley with spur-geared chain block H
2
touches stop-
per 13 in rail 12.
2010 / 50−D
Removal and Fitting of Scavenge Air Cooler (with Integrated Lifting IL
)
