5. Connecting to the network

Xerox Phaser 790

5–8

Windows NT 4.0 server environment

Windows NT 4.0 workstation

or Windows NT server

acting as print server

Printer

TCP/IP (lpd) for printing

TCP/IP (http) for Fiery WebTools

TCP/IP for Fiery utilities

Windows

workstation

Windows NT 4.0 workstation

with TCP/IP loaded

LAN with

NETBEUI, etc.

Printing on this network:

Windows 95/98 workstations can print using

a protocol available on the Windows NT 4.0

print server. Windows 4.0 machines can

print using TCP/IP with the lpd protocol.

For using Fiery utilities and WebTools:

A Windows NT 4.0 workstation with TCP/IP

loaded

NETBEUI or other protocol

available on the workstations

and the server

TCP/IP

Windows

workstation

Another

supported

protocol
