Clearing Area 5 jams 23. Problem Solving

Xerox Phaser 790 23-19

Clearing the Upper Inverter

1. In order to access Area 5, pull open the Upper Inverter.

301260

2. To release any paper, lift the green lever, and gently pull the paper in

the direction of the arrow

030

W O L

3. If the paper is not visible, turn the green knob in the direction of the

arrow.

301261a
