5. Connecting to the network

Xerox Phaser 790

5–11

Parallel port connection

A supported

network protocol

Printer

Parallel input

PC workstation,

server or laptop

Protocol not

directly supported

Parallel

With the parallel port enabled, the

printer can accept and print jobs

sent to its parallel port
