13. Installing the Fiery software for Windows and Macintosh

Xerox Phaser 790

13–22

Setting up Client Workstations to use Fiery WebTools

1. Enable TCP/IP networking.

2. Ensure that the workstation has a valid, unique IP address.

3. Ensure that the workstation is installed with one of the following

Internet browsers:

• Windows 95/98, Windows 2000 and Windows NT 4.0: Either

Netscape Communicator v 4.5 or later or Microsoft Internet

Explorer v4.0.1 and SP1 or later

• Mac OS: Netscape Communicator v 4.5 or later or Microsoft

Internet Explorer v4.0.1 or later with Java enabled

Netscape and Microsoft continue to release frequent updates to their

browsers. As support cannot be guaranteed for all versions, use the versions

specified above for best results.

4. Ensure that Java is enabled in your browser.
